| System | |
| CPU | 6th/7th Gen Intel® Xeon® E3/Core™ S (formerly Skylake/Kaby Lake) |
| LGA1151 socket type CPU (supports TDP up to 35W) | |
| Intel®C236 Chipset | |
| Chipset | Intel®C236 Chipset |
| Memory | 2x DDR4 SO-DIMM Max. 64GB (Skylake: DDR4-2133; Kaby Lake: DDR4-2400) |
| Graphic | Xeon®: HD Graphics P530 (Skylake)/P630 (Kaby Lake) |
| Core™ I Series: HD Graphics 530 (Skylake)/630 (Kaby Lake) | |
| Pentium®/Celeron®: HD Graphics 510 (Skylake)/610 (Kaby Lake) | |
| BIOS | AMI 128Mbit SPI BIOS |
| AI Controller (AIC) | AI for system monitoring and predictive analysis |
| Watchdog Timer | Runtime: 10 – 65535 seconds |
| Powerup: 120 – 65535 seconds | |
| TPM (optional) | SLB9665 (TPM 2.0) / SLB9635 (TPM 1.2) |
| POWER | |
| DC Input | 9~36VDC |
| Surge Protection | 200V/1ms |
| Power in Protection | Reverse-Voltage, Over-Voltage, Under-Voltage, Over-Current |
| Remote/Ignition | 1x ATX power on/off switch, 5-pin terminal block including 3-pin remote control |
| and 2-pin ignition signals (pitch 3.81 mm) | |
| Power Mode | AT/ATX (BIOS setting) |
| Mechanical | |
| Dimensions (W x D x H) | 260(W) x 206(D) x 77.42(H) mm (10.24″ x 8.11″ x 3.05″) |
| Weight (net/gross) | 3.7kg |
| Mounting | Foot stand; wall mount bracket (optional) |
| Construction | Aluminum and metal chassis with fanless design |
| Battery | Easily replaceable RTC battery holder |
| Dynamic Display | 0.96 inch LCM work with AIC to display system status |
| Module (DDM) | |
| External IO | |
| Display Ports / | 2x DP/4096×2304@60Hz |
| Resolution | 1x DVI-D/1920×1200@60Hz |
| 1x VGA/1920×1200@60Hz | |
| Triple Display Ports | 2x DP + 1x DVI-D |
| Combinations | 2x DP + 1x VGA |
| 1x DP + 1x DVI-D + 1x VGA | |
| Ethernet | 2x RJ45 GbE (Intel®i219 + Intel®i210) / Wake-on-LAN and PXE/ |
| i219 supports iAMT 11.0 | |
| PoE | 4x RJ45 GbE PoE+ (Intel®i210 ) 802.3at support up to 30W |
| USB 3.0/2.0 | 6x USB 3.0 ports via native XHCI controller (0.9A each port) |
| COM | 2x RS-232/422/485 (auto flow control), 4x RS-232 port |
| Digital I/O | 16-bit programmable DIO (AIH) |
| 8-bit isolated DI & 8-bit isolated DO, Sink/Source Mode, 5~48V, 100mA (AIH-i) | |
| Audio | ALC892 HD Audio Codec, Mic in, Line out |
| SIM | 3x SIM push-push slots |
| Storage | |
| Internal Drive Bay | 3x internal SATA port for 2.5” HDD/SSD |
| mSATA | 3x full length mSATA (muxed with Mini-PCIe) |
| Removable Drive Bay | NA |
| RAID Mode | RAID 0/1/5 |
| Expansion slot | |
| Mini-PCIe | 3x full length Mini-PCIe (muxed with mSATA, auto detection) |
| IOM1 (optional) | Supports IOM1 module |
| Other | |
| USB 2.0 Dongle | Internal 1x USB 2.0 for dongle security key |
| Antenna | 4x antenna openings |
| LED | Power status, HDD status, IO status |
| Environment | |
| Operating Temperature | Standard: -20°C to 50°C (-4°F~122°F), supports 35W TDP CPU |
| Extended temperature: -25°C to 70°C (-13°F~158°F) (For more | |
| information, please contact your representative) | |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 95% @ 40°C (104°F), non-condensing |
| Vibration During Operation | |
| (IEC60068-2-64: Random | 5Grms with SSD |
| 5~500Hz) | |
| Shock During Operation | |
| (IEC60068-2-27: Half Sine, | 50Grms with SSD |
| 11ms Duration) | |
| Certification | |
| EMC | CE/FCC Class A |
| Safety Certifications | CB |
| OS Support | |
| Optional OS Installation | Windows 7 32-bit/64-bit (Skylake only) |
| Windows 8.1 32-bit/64-bit (Skylake only) | |
| Windows Embedded Standard 7(Skylake only) | |
| Windows Embedded 8 Standard (Skylake only) | |
| Windows 10 64-bit | |
| Windows 10 IoT | |
| Linux |
