Features

■ It is a fiber in which the sensing distance is limited to a specific range so it is not easily affected by the background. It is effective when a workpiece is accumulated or when the background is near.

[fusion_table fusion_table_type=”1″ fusion_table_rows=”” fusion_table_columns=”” margin_top=”1ps” margin_right=”” margin_bottom=”” margin_left=”” hide_on_mobile=”small-visibility,medium-visibility,large-visibility” class=”” id=”” animation_type=”” animation_direction=”left” animation_color=”” hue=”” saturation=”” lightness=”” alpha=”” animation_speed=”0.3″ animation_delay=”0″ animation_offset=””]

Type Shape of fiber head
(mm)		 Model No. Bending
radius
(mm)		 Fiber
cable
length		 Free-cut Protection Ambient
temp.
Glass substrate detection Mapping

W25×H7.3×D30		 FD-L32H R4
Bending
durability		 4m Available IP40 -40 to
+60℃
Alignment

W20×H29×D3.8		 tough
FD-L30A		 R2
Bending
durability		 3m 0 to
+70℃
Alignment

W23.5×H29×D4.5		 tough
FD-L31A		 R4
Bending
durability
Alignment

W17×H29×D3.8		 tough
FD-L22A		 R2
Bending
durability		 2m
Seating confirmation

W18×H29×D3.8		 tough
FD-L23		 3m -20 to
+70℃
Seating confirmation

W12×H19×D3		 tough
FD-L11		 R4
Bending
durability		 2m -40 to
+60℃
Seating confirmation

W12×H19×D3		 tough
FD-L10

W24×H21×D4		 tough
FD-L21		 R2
Bending
durability

W24×H21×D4		 FD-L21W R1
General purpose
W6×H18×D14		 tough
FD-L20H		 R2
Bending
durability		 -40 to
+70℃
Ultla-small
W7.2×H7.5×D2		 FD-L12W R1 1m IP30 -40 to
+60℃

[/fusion_table]

[fusion_table fusion_table_type=”1″ fusion_table_rows=”” fusion_table_columns=”” margin_top=”1ps” margin_right=”” margin_bottom=”” margin_left=”” hide_on_mobile=”small-visibility,medium-visibility,large-visibility” class=”” id=”” animation_type=”” animation_direction=”left” animation_color=”” hue=”” saturation=”” lightness=”” alpha=”” animation_speed=”0.3″ animation_delay=”0″ animation_offset=””]

Refer to “Digital Fiber Sensor FX-550/FX-550L List of fibers”, “Digital Fiber Sensor FX-500 Ver.2 List of fibers” and “Digital Fiber Sensor FX-100 List of fibers” for the sensing range.
・ tough:
Refers to a fiber which possesses both unbreakable (bending radius: R10 mm R0.394 in, reciprocating bending: 180°) and more flexible (bending radius: R4 mm R0.157 in or less) features.
