Part Number: 1065879
Photoelectric Sensors Model: GL10-P4112
OEM Spec Ref
Features
| Functional principle | Photoelectric retro-reflective sensor |
| Functional principle detail | Dual lens |
| Dimensions (W x H x D) | 20 mm x 50 mm x 39 mm |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 0.08 m … 15 m 1)
0.08 m … 12 m 2) |
| Sensing range | 0.15 m … 12 m 1)
0.15 m … 10 m 2) |
| Type of light | Visible red light |
| Light source | PinPoint LED 3) |
| Light spot size (distance) | Ø 58 mm (5 m) |
| Wave length | 625 nm |
| Adjustment | None |
Mechanics/electronics
| Supply voltage | 10 V DC … 30 V DC 1) |
| Ripple | < 5 Vpp 2) |
| Current consumption | 20 mA |
| Switching output | PNP |
| Switching mode | Light/dark switching |
| Switching mode selector | Selectable via light/dark selector |
| Output current Imax. | ≤ 100 mA |
| Response time | ≤ 500 µs 3) |
| Switching frequency | 1,000 Hz 4) |
| Connection type | Male connector M12, 4-pin |
| Circuit protection | A 5)
B 6) C 7) D 8) |
| Protection class | III |
| Weight | 35 g |
| Polarisation filter | ✔ |
| Housing material | Plastic, ABS/PMMA |
| Enclosure rating | IP67 |
| Items supplied | Mounting bracket BEF-G10DC01, Reflector P250 |
| Electromagnetic compatibility (EMC) | EN 60947-5-2 |
| Ambient operating temperature | –30 °C … +60 °C |
| Ambient temperature, storage | –40 °C … +70 °C |
| UL File No. | NRKH.E348498 & NRKH7.E348498 |
| More standards | UL325 9) |
| Weight | 0.148 kg |
|---|---|
| Dimensions | 6 × 5.3 × 10 cm |
