GV-77U5WP IDS Imaging

IDS imaging camera was the easiest integration cameras in the market. Therefore, is so easy for IDS cameras become most compatible with market most popular machine vision software such as OpenCV, Labview, Cognex and Halcon vision software. IDS also provide wide range of industrial C-mount cameras such GigE 5, GigE 10, GigE, USB 2.0, USB 3.0, and USB 3.1 interfacing models.

For find out more IDS Imaging please follow the link.

Meanwhile, if you need technical support, please email us sales@inosaki.my

IDS Imaging Camera Features

The onsemi sensor XGS 45000 reaches enormous dimensions in terms of resolution – it delivers impressive 44.84 MPix (8200 x 5468, pixel size 3.20 µm)! This enables the GV-77U5WP industrial camera to capture even the smallest details, for example in panel inspection. It is also highly recommended when large scenes need to be inspected and evaluated precisely. The image data is forwarded via the extremely powerful 10GigE interface, whereby the camera achieves 17.0 fps.

This model is available in both monochrome and colour versions. The CMOS global shutter sensor has a format of 2″ and an aspect ratio of 3:2. Due to the sensor size, we offer this uEye+ Warp10 camera with a TFL mount (M35x0.75). For secure mounting, the TFL lenses can be firmly screwed to the cameras. The flange focal distance is standardised and corresponds with 17.526 mm to that of the C-mount models. You will find suitable lenses listed under accessories.

To ensure optimal image quality, we recommend the use of an Active Heat Sink (accessory, optional) for cooling.

Like all camera models of the uEye Warp10 family, the camera is GenICam compliant and therefore compatible with our IDS peak software development kit.

Camera Data
