This ABSOLUTE Digimatic Thickness Gauge enables you to measure film, paper, etc., with flat contact points.
| Inch-Metric: |
Inch/Metric
|
| Functions: |
With indicator ID-S No. 543-783BS (ANSI/AGD type)
|
| Digital step: |
0,0005″/0,01 mm
|
| Accuracy: |
±0,001″ / ±20 µm
|
| Measuring force: |
≤ 1,5 N
|
| Parallelism: |
0,0005″
|
| Indicator No.: |
543-400BS (ID-C)
|
| Max. measuring depth: |
30 mm
|
| Alarm: |
Low voltage, counting value composition error, overflow error, tolerance limit setting error (ID-C only)
|
| Contact point: |
Thread # 4-48UNF
|
| Power supply: |
1 battery SR-44
|
| Battery life: |
approx. 7000 hours
|
| DATA/HOLD: |
Yes
|
| PRESET: |
Yes
|
| Digimatic data output: |
Yes
|
| ON/OFF: |
Yes
|
| Function lock: |
Yes
|
| GO/±NG judgement: |
Yes
|
| ABS / INC (INC ZERO): |
Yes
|
| Calculation function (with formula): |
Yes
|
| Counting direction switchable: |
Yes
|
| Digimatic S1 Bidirectional interface: |
Yes
|
| Analog bar resolution selection: |
Yes
|
| Auto Power OFF setting: |
Yes
|
| Analog bar resolution switchable: |
Yes
|
| Customizing keys: |
Yes
|
| Inch/Metric switchable: |
Yes
|
| Calibration warning function: |
Yes
|
| Digital step switchable: |
Yes
|
All products of product family Series 547:
 |
Digital Thickness Gauge, Flat Type |  |
ABS Digital Thickness Gauge with ID-S |
| 0-10mm, 0,01mm | Inch/Metric, 0-0,47″, 0,0005″, 4,72″ Throat | ||
| Mitutoyo Digital Thickness Gauge Part Number: 547-301A | Mitutoyo ABS Digital Thickness Gauge Part Number: 547-520S | ||
| For more : sales@axmatic.com | For more : sales@axmatic.com | ||
 |
ABS Digital Thickness Gauge |  |
ABS Digital Thickness Gauge |
| 0-10mm, , 0,01mm, Groove Depth | Inch/Metric, 0-0,4″, 0,0005″, Lens Thickness | ||
| Mitutoyo ABS Digital Thickness Gauge Part Number: 547-315 | Mitutoyo ABS Digital Thickness Gauge Part Number: 547-312S | ||
| For more : sales@axmatic.com | For more : sales@axmatic.com | ||
 |
Digital Thickness Gauge, Deep Throad | |
Digital Thickness Gauge, Flat Type |
| 0-10mm, 0,01mm | Inch/Metric, 0-0,4″, 0,0005″ | ||
| Mitutoyo Digital Thickness Gauge Part Number: 547-321A | Mitutoyo Digital Thickness Gauge Part Number: 547-300A | ||
| For more : sales@axmatic.com | For more : sales@axmatic.com | ||
 |
Digital Thickness Gauge, Lens Thickness |  |
Digital Thickness Gauge, Blade Type |
| 0-10mm, 0,01mm | Inch/Metric, 0-0,4″, 0,0005″ | ||
| Mitutoyo Digital Thickness Gauge Part Number: 547-313A | Mitutoyo Digital Thickness Gauge Part Number: 547-316A | ||
| For more : sales@axmatic.com | For more : sales@axmatic.com | ||
 |
ABS Digital Thickness Gauge with ID-S |  |
Digital Thickness Gauge, Lens Thickness |
| Inch/Metric, 0-0,47″, 0,0001″, Standard | Inch/Metric, 0-0,47″, 0,0005″ | ||
| Mitutoyo ABS Digital Thickness Gauge Part Number: 547-526S | Mitutoyo Digital Thickness Gauge Part Number: 547-512A | ||
| For more : sales@axmatic.com | For more : sales@axmatic.com | ||
 |
ABS Digital Thickness Gauge with ID-S |  |
Digital Thickness Gauge, Blade Type |
| 0-10mm, 0,01mm, 120mm Throat | Inch/Metric, 0-0,47″, 0,0005″ | ||
| Mitutoyo ABS Digital Thickness Gauge Part Number: 547-321 | Mitutoyo Digital Thickness Gauge Part Number: 547-516A | ||
| For more : sales@axmatic.com | For more : sales@axmatic.com | ||
 |
Digital Thickness Gauge, Deep Throad | ||
| Inch/Metric, 0-0,4″, 0,0005″ | |||
| Mitutoyo Digital Thickness Gauge Part Number: 547-320A | |||
| For more : sales@axmatic.com | |||
Optional accessories:
 |
Digimatic Cable, Straight, 1m |  |
U-WAVE fit Bluetooth, Buzzer Type (not IP rated) |
| Digimatic/Digimatic 2/Digimatic S1 Interface | Wireless Transmitter for Micrometer | ||
| 06AGL011 | 264-627 | ||
| For more : sales@axmatic.com | For more : sales@axmatic.com | ||
 |
Digimatic Cable, Straight, 2m |  |
U-WAVE fit Bluetooth, IP67 Type |
| Digimatic/Digimatic 2/Digimatic S1 Interface | Wireless Transmitter for Micrometer | ||
| 06AGL021 | 264-626 | ||
| For more : sales@axmatic.com | For more : sales@axmatic.com | ||
 |
USB Input Tool Direct, Indicator Type |  |
Connection Unit Indicator |
| 2m Cable, Digimatic/Digimatic 2/Digimatic S1 Interface | 12,7mm/0,5” Type, U-WAVE fit, U-WAVE fit Bluetooth | ||
| 06AGQ001F | 02AZF700 | ||
| For more : sales@axmatic.com | For more : sales@axmatic.com | ||
 |
U-WAVE fit, Buzzer Type (not IP rated) |  |
U-WAVE-T Connection Cable SF |
| Wireless Transmitter for Micrometer | for Digimatic S1 Interface | ||
| 264-623 | 02AZG011 | ||
| For more : sales@axmatic.com | For more : sales@axmatic.com | ||
 |
U-WAVE fit, IP67 Type | ||
| Wireless Transmitter for Micrometer | |||
| 264-622 | |||
| For more : sales@axmatic.com | |||
Consumable spares:
 |
Battery SR44 1.5V |
| 938882 | |
| For more : sales@axmatic.com |
