Original price was: $ 140.99.$ 111.09Current price is: $ 111.09.
This is a back plunger, dial indicator with bezel ø 40 mm. It offers you the following benefits:
| Digital/Analog: |
Analog
|
| Inch-Metric: |
Metric
|
| Range: |
5 mm
|
| Range per rev.: |
1 mm
|
| Graduation: |
0.01 mm
|
| Graduation: |
0.01
|
| Measuring force: |
0,4-1,4
|
| MPE any 1/10 revolution: |
7 µm
|
| MPE any 1/2 revolution: |
11 µm
|
| MPE any 1 revolution: |
12 µm
|
| MPE measuring range: |
18 µm
|
| H MPE (Hysteresis): |
4 µm
|
| R MPE (Repeatability): |
3 µm
|
| Stem: |
8 mm
|
| Contact point: |
Carbide tipped, thread: M 2.5 x 0.45 mm
|
| Balanced dial: |
Yes
|
| Mass: |
80 g
|
| fu: |
4 µm
|
| Functions: |
ISO type
|
| A: |
40 mm
|
| B: |
22.7 mm
|
| C: |
35.6 mm
|
| E: |
24.3 mm
|
| F: |
25 mm
|
| G: |
13.8 mm
|
| H: |
43.3 mm
|
All products of product family Series 1:
 |
Dial Gauge, Lug Back, ISO Type |
| Back Plunger Design, Reverse Dial Face, 5mm, 0,01mm | |
| Mitutoyo Dial Gauge Part Number: 1162A | |
| For more : sales@inosaki.com | |
_psd.webp) |
Dial Gauge, Lug Back, ISO Type |
| Back Plunger Design, One Revolution, Shockproof, 1mm, 0,01mm | |
| Mitutoyo Dial Gauge Part Number: 1960A | |
| For more : sales@inosaki.com | |
 |
Dial Gauge, Lug Back, ANSI/AGD Type |
| Back Plunger Design, 0,2″, 0,001″ | |
| Mitutoyo Dial Gauge Part Number: 1167A | |
| For more : sales@inosaki.com | |
 |
Dial Gauge, Lug Back, ANSI/AGD Type |
| Back Plunger Design, Reverse Dial Face, 0,2″, 0,001″ | |
| Mitutoyo Dial Gauge Part Number: 1168A | |
| For more : sales@inosaki.com | |
 |
Dial Gauge, Lug Back, ANSI/AGD Type |
| Back Plunger Design, One Revolution, Shockproof, 0,04″, 0,001″ | |
| Mitutoyo Dial Gauge Part Number: 1961A | |
| For more : sales@inosaki.com |
Optional accessories:
 |
Limit Hands (Green) 2 pcs. |
| Dial Indicator Series 1, Test Indicator | |
| 21AAB363 | |
| For more : sales@inosaki.com | |
 |
Holding Bar for Back Plunger Indicator |
| Ø6mm, 42mm Length | |
| 21AAA166 | |
| For more : sales@inosaki.com | |
|
Holding Bar for Back Plunger Indicator |
| Ø6mm, 81mm Length | |
| 136567 | |
| For more : sales@inosaki.com | |
 |
Holding Bar for Back Plunger Indicator |
| Ø6,35mm, 81mm Length | |
| 124625 | |
| For more : sales@inosaki.com | |
|
Holding Bar for Back Plunger Indicator |
| Ø6,35mm, 42mm Length | |
| 21AAA167 | |
| For more : sales@inosaki.com | |
|
Holding Bar for Back Plunger Indicator |
| Ø8mm, 42mm Length | |
| 21AAA168 | |
| For more : sales@inosaki.com | |
|
Holding Bar for Back Plunger Indicator |
| Ø8mm, 81mm Length | |
| 136568 | |
| For more : sales@inosaki.com |
Consumable spares:
 |
Contact Element Ball Point, M2,5×0,45 |
| 8,3mm Length, Metric | |
| 21AZA319 |
| Weight | 0.080 kg |
|---|
