An economical, slim-style Mitutoyo digital indicator with an extemely long battery life suited to installation in measuring jigs where access may be restricted. ABSOLUTE System scale for error free, high-speed measurement. SPC data output.
| Digital/Analog: |
Digital
|
| Inch-Metric: |
Metric
|
| Range: |
25.4 mm
|
| Digital step: |
0.01 mm
|
| Max. Permissible Error E MPE (Total Range): |
0.02 mm
|
| H MPE (Hysteresis): |
0.02 mm
|
| R MPE (Repeatability): |
0.01 mm
|
| Measuring force: |
≤ 1,8 N
|
| Protection: |
IP42
|
| Type: |
EN ISO Standard
|
| Scale: |
Electrostatic capacitance type absolute linear encoder
|
| Display: |
LCD, character height 8.5 mm
|
| Max. response speed: |
Unlimited
|
| Alarm: |
Low voltage, sensor error, ABS data composition error
|
| Stem Ø: |
8 mm
|
| Contact point: |
Carbide ball, thread: M2.5×0.45
|
| Power supply: |
1 battery SR44
|
| Battery life: |
Approx. 20000 hours
|
| Remarks: |
This digital indicator has data output but no integrated data button so for USB Input Tool Direct Cable (see optional accessory) the USB-ITPAK Software is required.
|
| Digimatic data output: |
Yes
|
| ON/OFF: |
Yes
|
| ORIGIN (ABS-Zero): |
Yes
|
| Counting direction switchable: |
Yes
|
| Mass: |
140 g
|
All products of product family Series 575:
 |
Digital Indicator ID-U |
| Inch/Metric, 1″, 0,0005″/0,01mm | |
| Mitutoyo Digital Indicator Part Number: 575-122 | |
| For more : sales@axmatic.com | |
 |
Digital Indicator ID-U, ANSI/AGD |
| Inch/Metric, 1″, 0,0005″/0,01mm | |
| Mitutoyo Digital Indicator Part Number: 575-123 | |
| For more : sales@axmatic.com |
Optional accessories:
 |
Digimatic Cable, Flat Straight Type |
| 1m | |
| 905338 | |
| For more : sales@axmatic.com | |
|
Digimatic Cable, Flat Straight Type |
| 2m | |
| 905409 | |
| For more : sales@axmatic.com | |
 |
USB Input Tool Direct (Digimatic USB) |
| Digi/Digi2, Flat Straight Type | |
| 06AFM380F | |
|
For more : sales@axmatic.com |
|
 |
Digimatic Input Tool USB |
| HID/VCP Interface Digimatic/Digimatic2 | |
| 264-016-10 | |
| For more : sales@axmatic.com | |
 |
U-WAVE-T, Buzzer Type |
| Wireless Transmitter | |
| 02AZD880G | |
| For more : sales@axmatic.com | |
 |
U-WAVE-T, IP67 Type |
| Wireless Transmitter | |
| 02AZD730G | |
| For more : sales@axmatic.com | |
 |
U-WAVE-T Connection Cable F |
| Flat Straight Type | |
| 02AZD790F | |
| For more : sales@axmatic.com | |
 |
Spindle Lifting Cable |
| for Indicator, L=500mm | |
| 21JZA295 | |
| For more : sales@axmatic.com | |
 |
Spindle Lifting Cable with Auto Stop |
| for Indicator, L=300mm | |
| 21JZA301 | |
| For more : sales@axmatic.com |
Standard accessories:
 |
Spindle Lifting Handle for Indicator |
| for Plunger | |
| 137693 | |
| For more : sales@axmatic.com |
Consumable spares:
 |
Battery SR44 1.5V |
| 938882 | |
 |
Contact Element Ball Point, M2,5×0,45 |
| 7,3mm Length, Carbide, Metric | |
| 901312 |
| Weight | 0.140 kg |
|---|
