The Applications of SICK WSE9-3P2230 Photoelectric Sensor
1. Transparent Bottle Detection on High-Speed Filling Lines
In beverage production, detecting clear bottles filled with transparent liquids can be challenging. The SICK WSE9-3P2230 uses a precise red PinPoint LED beam that cuts through reflective surfaces to ensure each bottle is detected accurately, even when moving rapidly. Its 1,000 Hz switching speed and <0.5 ms response time enable smooth synchronization with filling and capping stations. The rugged IP69K-rated housing withstands moisture, cleaning sprays, and temperature fluctuations, minimizing false readings and ensuring consistent line productivity.
2. Counting Small Parts on Conveyor Systems
In fast-moving assembly lines, tiny components often pass by too quickly for standard sensors to register. The WSE9-3P2230 solves this by combining a long 10 m detection range with high-frequency switching, allowing accurate counting of miniature or irregularly shaped parts without interruption. Its compact rectangular housing fits easily in limited spaces along conveyor belts, while the robust optical design maintains reliable detection under vibration or varying lighting conditions, ensuring precision and high throughput in production.
3. Reliable Operation in Harsh Industrial Environments
Factories that handle food, chemicals, or heavy machinery require sensors that resist washdowns, dust, and mechanical stress. The WSE9-3P2230 excels in such environments thanks to its sealed IP66/IP67/IP69K enclosure and corrosion-resistant VISTAL® body. Even under high-pressure cleaning or oil exposure, it delivers stable readings. Maintenance needs are reduced due to its fixed optical alignment and non-contact sensing, which helps keep processes running without sensor recalibration or frequent cleaning interruptions.
4. Monitoring Transparent Films in Packaging Machines
In automated packaging, thin or clear films can be difficult to detect, leading to misfeeds and wasted materials. The WSE9-3P2230 provides a focused light spot and exceptional operating reserve to identify even minimal changes in light intensity as films move or shift. This enables accurate edge detection, film tracking, and tension control. The result is fewer sealing errors, reduced film waste, and higher machine efficiency — essential for consistent, high-quality packaging performance.
Related Products & Accessories – Compatible with SICK WSE9-3P2230 (1049076)
| Category | Product Name / Description | Part Number | Purpose / Benefit |
|---|---|---|---|
| Mounting Bracket | Mounting Bracket for W9 Series (zinc-coated steel) | 2022855 | Provides stable mounting and precise alignment for the WSE9-3P2230 on machinery or conveyor frames. |
| Mounting Plate | Universal Clamp Plate N08, zinc die-cast steel | 2051607 | Allows flexible installation of W9 sensors across multiple orientations; includes mounting hardware. |
| Mounting Plate (Stainless Steel) | Universal Clamp Plate N11N, stainless steel | 2071081 | Corrosion-resistant option for hygienic or food-grade environments requiring frequent washdowns. |
| Sensor/Actuator Cable (PVC) | M8 4-pin female straight to flying leads, 5 m, PVC | 2095889 | Standard unshielded connection cable suitable for dry or clean environments. |
| Sensor/Actuator Cable (PUR) | M8 4-pin female straight to flying leads, 5 m, PUR | 2094792 | Durable, halogen-free cable for use in oily or mobile applications like robots or drag chains. |
| Connector Plug | M8 4-pin male connector, straight, screw-type terminal | 6037323 | Enables secure field wiring and fast installation into existing systems. |
| Matching Receiver Unit | Photoelectric receiver for W9 through-beam sensor system | 2055822 | Works with the WSE9-3P2230 transmitter for full through-beam detection functionality. |
| Alternate Transmitter Model | W9 transmitter for short-range or special setup requirements | 2055821 | Used as a transmitter in the W9 family, adaptable for custom sensing arrangements. |
