| Input Number of phases | 3 AC |
| Input Line voltage | 380 ... 440 V +10%-20% |
| Input Line frequency | 47 ... 63 Hz |
| Input Rated current (LO) | 28.50 A |
| Output Number of phases | 3 AC |
| Output Rated voltage | 400 V |
| Output Rated power IEC 400V (LO) | 15.00 kW |
| Output Rated current 400V (IN) | 31.00 A |
| Output Rated current 380V (IN) | 31.00 A |
| Output Rated current (LO) | 31.00 A |
| Output Max. output current | 34.10 A |
| Output Pulse frequency | 4 kHz |
| Output frequency for vector control | 0 ... 240 Hz |
| Output frequency for V/f control | 0 ... 550 Hz |
| Overload capability Low Overload (LO) | 110% base load current IL for 60 s in a 600 s cycle time |
| Standard digital inputs Number | 6 |
| Standard digital inputs Switching level: 0 → 1 | 11 V |
| Standard digital inputs Switching level: 1 → 0 | 5 V |
| Standard digital inputs Max. inrush current | 15 mA |
| Fail-safe digital inputs Number | 0 |
| Digital outputs Number as relay changeover contact | 4 |
| Digital outputs Output (resistive load) | DC 30 V, 1.0 A |
| Digital outputs Number as transistor | 0 |
| Analog / digital inputs Number | 2 (Differential input) |
| Analog / digital inputs Resolution | 12 bit |
| Switching threshold as digital input 0→1 | 4 V |
| Switching threshold as digital input 1→0 | 1.6 V |
| Analog outputs Number | 2 (Non-isolated output) |
| PTC/KTY interface | 1 motor temperature sensor input, sensors that can be connected: PTC, KTY, PT1000 and Thermo-Click, accuracy ±5 °C |
| Power factor λ | 0.75 ... 0.93 |
| Power factor cos φ 1 | 0.99 |
| Efficiency η | 0.98 |
| Sound pressure level (1m) | 67 dB |
| Power loss | 0.422 kW |
| Filter class (integrated) | Unfiltered |
| EMC category (with accessories) | without |
| Safety function "Safe Torque Off" | without SIRIUS device (e.g. via S7-1500F) |
| Communication | USS, Modbus RTU, BACnet MS/TP |
| Standard board coating type | Class 3C2, according to IEC 60721-3-3: 2002 |
| Cooling | Air cooling using an integrated fan |
| Cooling air requirement | 0.018 m³/s (0.653 ft³/s) |
| Installation altitude | 1,000 m (3,280.84 ft) |
| Ambient temperature Operation | -20 ... 60 °C (-4 ... 140 °F) |
| Ambient temperature Transport | -40 ... 70 °C (-40 ... 158 °F) |
| Ambient temperature Storage | -40 ... 70 °C (-40 ... 158 °F) |
| Relative humidity Max. operation | 95% At 40 °C (104 °F), condensation and icing not permissible |
| Signal cable Conductor cross-section | 0.15 ... 1.50 mm² (AWG 24 ... AWG 16) |
| Line side Version | screw-type terminal |
| Line side Conductor cross-section | 1.50 ... 16.00 mm² (AWG 16... AWG 6) |
| Motor end Version | Screw-type terminals |
| Motor end Conductor cross-section | 1.50 ... 16.00 mm² (AWG 16 ... AWG 6) |
| PE connection | On housing with M4 screw |
| Max. motor cable length Shielded | 150 m (492.13 ft) |
| Max. motor cable length Unshielded | 300 m (984.25 ft) |
| Degree of protection | IP20 / UL open type |
| Frame size | FSC |
| Compliance with standards | CE, EAC, RCM, ROHS II |
| CE marking | EMC Directive 2004/108/EC, Low-Voltage Directive 2006/95/EC |
| Converter losses to IEC61800-9-2* Efficiency class | IE2 |
| Physical Weight (kg) | 7 |
| Dimensions L x W x H (cm) | 20.9 x 14 x 29.5 |
