Manufacturer Part Number: Festo 150414
Festo Proximity Sensors: SIEN-M12NB-PO-K-L
The Festo SIEN-M12NB-PO-K-L, MPN 150414, is a state-of-the-art inductive proximity sensor meticulously designed for precise and reliable object detection in diverse industrial settings. This sensor boasts a robust construction with a high degree of protection (IP65/IP67) and moderate corrosion resistance, ensuring durability under challenging conditions.
Key Features:
Benefits:
Applications:
The Festo SIEN-M12NB-PO-K-L stands out for its reliability and precision, making it a valuable component for any industrial sensor system.
| Feature | Specification |
|---|---|
| Conforms to standard | EN 60947-5-2 |
| Symbol | 00991613 |
| Certification | RCM compliance mark c UL us – Listed (OL) |
| CE marking (see declaration of conformity) | As per EU EMC directive |
| Rated operating distance | 4 mm |
| Assured operating distance | 3.24 mm |
| Reduction factors | Aluminum = 0.5 Stainless steel St 18/8 = 0.9 Copper = 0.5 Brass = 0.6 Steel St 37 = 1.0 |
| Ambient temperature | -25 °C … 70 °C |
| Repetition accuracy under constant conditions | 0.2 mm |
| Switching output | PNP |
| Switching element function | N/C contact |
| Hysteresis | ≤0.36 mm |
| Max. switching frequency | 2000 Hz |
| Max. output current | 200 mA |
| Voltage drop | ≤2 V |
| Inductive protective circuit | Installed |
| Short-circuit protection | Pulsed |
| DC operating voltage range | 10 V … 30 V |
| Residual ripple | ± 10% |
| Idle current | ≤10 mA |
| Reverse polarity protection | for all electrical connections |
| Electrical connection | Cable |
| Cable length | 2.5 m |
| Material of cable sheath | TPE-U(PUR) |
| Size | M12x1 |
| Type of mounting | With lock nut |
| Mounting type | Not flush |
| Product weight | 90 g |
| Housing material | Brass PBTP Nickel-plated |
| Switching status indication | LED yellow |
| Ambient temperature with flexible cable installation | -5 °C … 70 °C |
| Degree of protection | IP65 IP67 |
| Corrosion resistance class (CRC) | 2 – Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Selection of additional sensor information | With standard switching distance |
| Electrical output | PNP |
| Selection of sensor version | Standard |
| Weight | 0.090 kg |
|---|
