Weidmuller PRO ECO 72W 12V 6A DIN Rail Power Supply

Technical Overview

Compact, high-efficiency 72W 12V 6A switch-mode power supply for DIN rail mounting, featuring overload and short-circuit protection.

Key Features

DIN Rail mountable for easy integration into control panels.
Provides a stable 12V DC output at 6A.
Wide input voltage range: 85-264V AC or 80-370V DC.
High efficiency of 85%.
Comprehensive protection against inverse voltage, overload, short-circuit, and overheating.
Unrestricted capacitive load handling.
Compact design with a width of 34mm, suitable for space-constrained applications.
IP20 protection rating.
Adjustable output for flexible application.
Operating temperature range of -25 °C to +70 °C.

Technical Specification Matrix

Parameter	Value
Output Power	72 W
Output Voltage	12 V DC
Output Current	6 A
AC Input Voltage Range	85 V AC to 264 V AC
DC Input Voltage Range	80 V DC to 370 V DC
Efficiency	85%
Mounting Style	DIN Rail Mount
Operating Temperature	-25 °C to +70 °C
Storage Temperature	-40 °C to +85 °C
Insulation Voltage (Input/Output)	3 kV
Protection Rating	IP20
Protection Features	Overheating, Short Circuit, Overload, Inverse Voltage
MTBF	500,000 h
Approvals	CE, cULus, EAC, TUV, RoHS Compliant with exemption 7a, 7cI
Physical Weight (kg)	0.52
Dimensions L x W x H (cm)	10 x 3.4 x 12.5

Industrial Applications

1. Industrial Control Panel Power

Providing stable 12V DC power for programmable logic controllers (PLCs), human-machine interfaces (HMIs), sensors, and small actuators within compact industrial control cabinets.

Problem Solved

Ensures reliable and protected power delivery to sensitive control components in a confined industrial environment, leveraging DIN rail mounting for organized installation.

12V DCDIN Rail MountIP20Overload ProtectionCompact Design

2. Building Automation Systems

Supplying continuous and protected 12V DC power to various components in building automation setups, such as access control systems, HVAC controllers, and security sensors.

Problem Solved

Offers a robust and efficient power source that can withstand a wide operating temperature range and is easily integrated into standard building electrical enclosures, ensuring uninterrupted operation of critical building infrastructure.

12V DC72WOverheating ProtectionWide Temperature RangeBuilding Management

3. Small Machine Automation

Powering low-power automation modules, solenoids, and small motors in compact machinery like material handling systems, packaging equipment, or custom assembly stations.

Problem Solved

Delivers a reliable 12V DC, 6A output with essential protection features (short-circuit, overload) crucial for machinery, minimizing downtime due to electrical faults and supporting compact machine designs.

12V DC6A OutputShort Circuit ProtectionOverload ProtectionCompact Dimensions
