WL100-2P1332S08 Miniature Photoelectric Sensors – SICK Sensor

$ 101.66

SKU SICK 6058893 Category

SICK sensor one of the world’s leading producers of sensors and sensor solutions for industrial applications. SICK is a technology and market leader in Factory and Logistics Automation as well as Process Automation. The sensor range are: Laser Sensors, Cylinder Sensors, Photoelectric Sensors, Fork Sensors, Encoders, Color Sensors, Distance Sensor, Contrast Sensor, Color Sensor, Inductive Proximity Sensors, Fiber Optic Sensor with our signature range sick sensor intelligence.

Part Number:6058893
Photoelectric Sensor Model:WL100-2P1332S08
OEM Spec Ref

Features

Sensor/ detection principle Photoelectric retro-reflective sensor, Dual lens
Dimensions (W x H x D) 11 mm x 31 mm x 20 mm
Housing design (light emission) Rectangular
Sensing range max. 0.01 m … 7.2 m 1)
Sensing range 0.01 m … 5.5 m 1)
Type of light Visible red light
Light source LED 2)
Light spot size (distance) Ø 280 mm (4 m)
Wave length 632 nm
Adjustment None
  • 1) Reflector PL80A.
  • 2) Average service life: 100,000 h at TU = +25 °C.

Mechanics/electronics

Supply voltage 10 V DC … 30 V DC 1)
Ripple ± 10 % 2)
Current consumption 30 mA 3)
Switching output PNP
Switching mode Light switching
Signal voltage PNP HIGH/LOW UV – 1,8 V / ca. 0 V
Output current Imax. ≤ 100 mA
Response time ≤ 0.5 ms 4)
Switching frequency 1,000 Hz 5)
Connection type Cable, 3-wire, 5 m 6)
Cable material PVC
Conductor cross-section 0.18 mm²
Circuit protection 7)

8)

9)

Protection class III
Polarisation filter
Housing material Plastic, ABS/PC/POM
Optics material Plastic, PMMA
Enclosure rating IP67
Ambient operating temperature –25 °C … +55 °C
Ambient temperature, storage –40 °C … +70 °C
  • 1) Limit values.
  • 2) May not exceed or fall below Uv tolerances.
  • 3) Without load.
  • 4) Signal transit time with resistive load.
  • 5) With light/dark ratio 1:1.
  • 6) Do not bend below 0 °C.
  • 7) A = VS connections reverse-polarity protected.
  • 8) B = output reverse-polarity protected.
  • 9) D = outputs overcurrent and short-circuit protected.
